Overview:
The fingerprint security USB flash drive is a contact-based fingerprint recognition device primarily composed of a C*Core’s processor chip, fingerprint sensor, and storage chip. It is distinguished by durability, corrosion resistance, strong anti-static capabilities, small size, low power consumption, and high security.
Fingerprint processing, matching, and storage are all completed within the C*Core’s processor chip,ensuring fast processing speed. Moreover, fingerprint data is encrypted to ensure secure storage.
Advantages
? Low power consumption
? Capacitive semiconductor sensor
? Short matching time
? The fingerprint security USB flash drive has three partitions: optical disk, general area, and secure area.
- The optical disk partition stores related tools and user manuals.
- The general area is a plaintext area with the same function as a regular USB.
-The secure area is an encrypted area that is initially closed. After registering a fingerprint and granting permissions, touching at any time will unlock the Secure Area. It supports encrypted storage of USB data, ensuring data security.
-Multiple incorrect password entries will automatically lock the device.
? Optional Features
- Supporting Windows Hello function and is certified by the Windows Hardware Quality Labs (WHQL)
Appearance
Dimensions
| Dimensions | |
| Length | 65mm |
| Width | 20mm |
| Height | 10mm |
| Parameter | Description |
| Processor (MCU) | 32bit C*Core MCU C*Core’s 32-bit CPU |
| Sensor Type | Capacitive Semiconductor Sensor |
| Resolution | 508DPI |
| Image Grayscale Level | 256 Levels |
| FAR | 0.002% |
| FRR | ＜2% |
| Matching Time(1:10) | ＜400ms |
| Fingerprint Capacity | Standard configuration :10 Fingerprints |
| Operating Voltage | 4.5V~5.5V |
| Operating Current | ＜120mA(max.) |
| Service Life | Coating Surface Hardness 4H, >1 Million Lifespan |
| Data Interface | USB2.0 (Compatible with USB1.1) |
| Storage Capacity | 16GB/32GB/64G/128G |
| Read/Write Speed | Write::25MB/s(typ.)，Read:27MB/s(typ.) |
| Operating Environment | Temperature:0℃~70℃ |
| Storage Environment | Temperature:-40℃~85℃ |
The fingerprint security USB flash drive is primarily used by individuals or organizations who are sensitive of data security. Through the combination of fingerprint recognition and secure encrypted storage, it satisfies the legitimate use and secure storage of privacy data.
? Complete development environment
? Rich driver library
? Complete application solutions
