Overview:
The fingerprint security UKEY is a contact fingerprint recognition device primarily composed of the C*Core’s processor chip and fingerprint sensor. It is distinguished by durability, corrosion resistance, strong anti-static capabilities, small size, low power consumption, and high security.
The C*Core’s chip internally processes, matches, and stores fingerprints,which has a fast processing speed, It uses a USB interface, and serves as a secure carrier for digital certificates and private keys based on the public key infrastructure (PKI)..Key pairs are generated or imported within the UKEY while the private key cannot be exported, ensuring the information security of the certificate holder. Additionally, it supports a triple authentication mechanism of "hardware + fingerprint + password" to protect the legitimate use of digital certificates and private keys.
Advantages:
? Low power consumption
? Capacitive semiconductor sensor
? Short matching time
? Optional features
-Supporting Windows Hello function and is certified by the Windows Hardware Quality Labs (WHQL)
Appearance
Dimensions:
Dimensions | |
Length | 65mm |
Width | 20mm |
Height | 10mm |
Parameter | Description |
Processor (MCU) | 32bit C*Core CPU C*Core’s 32-bit CPU |
Sensor Type | Capacitive Semiconductor Sensor |
Resolution | 508DPI |
Image Grayscale Level | 256 Levels |
FAR | 0.002% |
FRR | <2% |
Matching Time(1:10) | <400ms |
Capacity | Standard configuration :10 Fingerprints |
Power Supply Voltage | 4.5V~5.5V |
Operating Current | <60mA |
Service Life | Coating Surface Hardness 4H, >1 Million Lifespan |
Data Interface | USB2.0 (Compatible with USB1.1) |
Operating Environment | Temperature: 0℃~70℃ |
Storage Environment | Temperature: -40℃~85℃ |
? The fingerprint security UKEY has a wide range of applications, including PKI authentication, digital signatures, data (real-time) encryption and decryption, and secure data storage. It can be used in various fields such as:
- Computer and internet, POS machines, and other identity authentication domains
- Copyright protection, licensing, government and enterprise office security management domains
- Insurance, finance, payment, and other financial security domains
? Complete development environment
? Rich driver library
? Complete application solutions
