Cloud Security Chip-CCP903T Series

The cloud security chip of CCP903T are high-performance single-core microprocessors independently developed by C*Core. It is designed based on the C9000 PowerPC core with 4-issue, 9-stage pipeline, superscalar architecture supporting SMP systems.

It supports algorithm allocating by hardware engine independent of CPU, enabling concurrent processing.

It supports EBC external bus. In addition, various peripherals are integrated on-chip, such as PCI-E2.0, USB2.0 Host, USB2.0 OTG, GPIO, SPI, QSPI, UART, I2C, etc.CCP903T series chips include CCP903T and CCP903T-M.

Block diagram of CCP903T series

Package Type

Interface	Package type and pin assignment(mm)
Interface	CCP903T BGA485 (17*17)
SPI	3
SSI	1
SNFC	1
I2C	3
UART	2
ISO7816	1
EBC	1
TRNG	1
JTAG	1
USB2.0-HOST	1
USB2.0-OTG	1
PCI-E 2.0	x4
SD/eMMC	1
GPIO	16

Functional Characteristics

CPU Features

? 4-issue RISC architecture
? 9-stage pipeline
? Super scalar
? 32KB instruction CACHE
? 32KB data CACHE
? 256KB L2 CACHE
On-Chip Memory Resources

? 512KB byte SRAM
? 1MB byte FLASH
Internal Modules

? AXI_DMA/EP_DMA
? 4 timers (PIT)
? Watchdog (WDT)
Secure bboot and memory

? Secure Boot: Authenticated encryption protection for user code
? Security debugging control: configurable debugging interface open and close
? Access control unit: authorized access control to address space
? Security Monitor: monitoring and collecting all security information in real time in order to determine the current security status of the chip
? A random root key in side to encrypt and protect the application system key
Secure detection and protection unit

? Voltage detection unit
? Frequency detection unit
? Temperature detection unit
? Power supply burr detection unit
? Light detection unit
? Physical detection protection
Encryption engine

? Supporting Symmetric algorithms: SM4/AES/DES/3DES
? Supporting Asymmetric algorithms: SM2/RSA1024/RSA2048
? Supporting Hashing algorithms: SM3/SHA1/SHA256/SHA384/SHA512/HMAC
? Hardware algorithm engine independent of CPU
? Protection for data stored in non-volatile memory and protection for data integrity
Other features

? Unique serial number for each product
? Power domain: 1.2V, 2.5V, 3.3V
? Commercial operating temperature：0-70 degrees
? Industrial operating temperature：-40~85 degrees
